Bucket Brooms - RBH – Large Bucket Broom- Forward Sweep

Our RBH-01 reverse sweep bucket brooms are Australian made and suitable for wheel loaders between 8Ð13 tonne. These bucket brooms are recommended for working over uneven ground and surfaces where mud and dirt is compacted on the ground.

Get a Quote
SKU: RBH Large Bucket Broom Forward Sweep Category:
Expertise in Skid Steer Attachments
Helping Customers all over the World
Quality Machinery - Outstanding Service

Product description

The RBH-01 reverse sweep bucket brooms couple to the existing quick hitch on your loader and uses the auxiliary hydraulics to drive the brush. The units are manufactured to 2400 mm (95Ó) with the overall width being 2880 mm (113Ó). Various sweeping widths with different bucket capacities are available including 1800mm (0.3m_), 2000mm (0.4m_) and 2400mm (0.5m_). For optimum sweeping efficiency, it is recommended that you reverse when sweeping. A 50/50 mixture of 860mm (34″) outside diameter poly and wire brush segments are supplied as standard although this ratio can be altered to suit your application. The main brush is driven directly off twin hydraulic motor via a urethane-coated drive coupling, thereby eliminating chain and sprockets wear parts.

Host Machine Size Wheel loader
(8Ð13 tonne)
Sweeping Width 1800mm, 2000mm,
Brush Diameter 860mm
Direction of Travel
when Sweeping
Forward or reverse
Bucket Capacity 1800mm bucket Ñ 0.3m_
2000mm bucket Ñ 0.4m_
2400mm bucket Ñ 0.5m_
Drive Mechanism Direct drive via coupling
(2 hydraulic motors)
Side Broom Option Yes
Hydraulic Flow
Cutting Edge Weld-on
Mass 1800mm bucket Ñ 950kg
2000mm bucket Ñ 1050kg
2400mm bucket Ñ 1200kg
